WEG SSW-05 - Diagnostic Configuration Mapping; P106 Parameter Explanation and Example; Diagnostic Configuration Value Mapping

English-26
ENGLISH
Installation and Operation Manual - SSW-05 Plus
LSB
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
MSB
Overcurrent
Phase loss
Incorrect phase sequence
Locked rotor
Motor overload
Automatic reset
-
-
-
-
-
-
-
-
-
-
Example:
P106 = 13 Hex
1 - Enabled - Overcurrent
1 - Enabled - Phase loss
0 - Disabled - Incorrect phase sequence
0 - Disabled - Locked rotor
1 - Enabled - Motor overload
0 - Disabled - Automatic reset
13Hex = 010011bin
Parameter Description / Notes
The Table below shows the combination of the enabled diagnostics and
the corresponding value to be programmed at P106.
Diagnostic Configuration
Value Programmed
at P106 (hexadecimal)
Automatic Reset Motor Overload Stall Incorrect Phase sequence Phase Loss Overcurrent
Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
10
11
12
13
14
15
