71 of 76
TECHNICIANS manual
ENGLISH
Par. Description min Def MAX Um
P158 Coee boiler PID derivative coecient 0 2.0 10.0 s
P160 Steam boiler PID proportional band 0.01 0.01 10.00 Bar
P161 Steam boiler PID integrative coecient 0 0
10000
s
P162 Steam boiler PID derivative coecient 0 0 10.0 s
P163 Services boiler temperature band 0 2 10.0 °C
P165 Set group temperature in deep_standby P62 65 P63 °C
P166 Set coee boiler temperature in deep_standby P62 65 P63 °C
P167 Set services boiler temperature in deep_standby P62 65 P63 °C
P168 Standby time to go to deep_standby 0 10 255 min
P200 Oset calculation/measurement boiler pressure -1.00 0.00 -1.00 bar
P201 Oset probe NTC Group 1 -20 -1 20 °C
P202 Oset probe NTC coee boiler group 1 -20 0 20 °C
P203 Oset probe NTC Group 2 -20 -1 20 °C
P204 Oset probe NTC coee boiler group 2 -20 0 20 °C
P205 Oset probe NTC Group 3 -20 -1 20 °C
P206 Oset probe NTC coee boiler group 3 -20 0 20 °C
P207 Oset probe NTC Group 4 -20 -1 20 °C
P208 Oset probe NTC coee boiler group 4 -20 0 20 °C
P209 Oset probe NTC services boiler -20 0 20 °C
P210 Oset probe NTC Autosteamer -20 0 20 °C
P211 Oset probe NTC cup-warmer -20 0 20 °C
P212 Oset probe NTC base card -20 0 20 °C
P213 Oset pump pressure measurement -1.00 0.00 -1.00 bar
P214 Adjustment for Autosteamer T1 0.0 13.0 20.0 °C
P215 Adjustment for Autosteamer T2 0.0 13.0 20.0 °C
P216 Adjustment for Autosteamer T3 0.0 8.0 20.0 °C
P220
Ambient Humidity Ratiometric Value associated
at 0%
0 0 100 %
P221
Ambient Humidity Ratiometric Value associated
at 100%
0 100 100 %
P222 Pressure Pump Ratiometric Value associated at 0% 0.0 0.0 10.0 Bar
P223 Pressure Pump Ratiometric Value associated at 100% 0.0 16.0 25.0 Bar
P224
Steam boiler Pressure Ratiometric Value associ-
ated at 0%
0.0 0.0 10.0 Bar
P225
Steam boiler Pressure Ratiometric Value associated
at 100%
0.0 4.0 10.0 Bar
P226
Steam boiler Pressure Ratiometric Voltage associ-
ated at 0%
0.0 0.5 5.0 Volt
P227
Steam boiler Pressure Ratiometric Voltage associ-
ated at 100%
0.0 4.5 5.0 Volt
P230 Input ow meter litre impulses 0 2000
10000
P231 Impulses litre ow meter coee group 1 0 2000
10000
P232 Impulses litre ow meter coee group 2 0 2000
10000
P233 Impulses litre ow meter coee group 3 0 2000
10000
P234 Impulses litre ow meter coee group 4 0 2000
10000
P235
Presence ow meter inlet
0 0 10 = Absent
1 = Present
P300 Modbus address for serial RS485 CN32 0 1 127
P301
Baudrate for serial RS485 CN32
0 1 2
0 = 4800 Baud
1 = 9600 Baud
2 = 19200 Baud
Par. Description min Def MAX Um
P302
Parity for serial RS485 CN32
0 2 3
0 = None (with 2 stop bits)
1 = ODD (1 stop bit)
2 = EVEN (1 stop bit)
3 = NONE (1 stop bit)
P303 Communication timeout for RS485 CN32 1 60 600 s
P305 Modbus address for serial RS485 CN31 (RFID) 0 1 127
P306
Baudrate for serial S485 CN31 (RFID)
0 1 2
0 = 4800 Baud
1 = 9600 Baud
2 = 19200 Baud
P307
Parity for serial S485 CN31 (RFID)
0 3 3
0 = None (with 2 stop bits)
1 = ODD (1 stop bit)
2 = EVEN (1 stop bit)
3 = NONE (1 stop bit)
P308 Communication timeout for RS485 CN31 (RFID) 1 60 600 s
P311
Baudrate for serial RS232 CN12 (cash register)
0 0 5
0 = 1200 Baud
1 = 2400 Baud
2 = 4800 Baud
3 = 9600 Baud
4 = 19200 Baud
5 = 38400 Baud
P312
Parity for serial RS232 CN12 (cash register)
0 2 3
0 = None (with 2 stop bits)
1 = ODD (1 stop bit)
2 = EVEN (1 stop bit)
3 = NONE (1 stop bit)
P313
Communication timeout for RS232 CN12 (cash
register)
0.1 1.0 60.0 s
P320
Baudrate CAN 1
0 2 3
0 = 125 Kbit
1 = 250 Kbit
2 = 500 Kbit
3 = 1 Mbit
P321
Baudrate CAN 2
0 2 3
0 = 125 Kbit
1 = 250 Kbit
2 = 500 Kbit
3 = 1 Mbit
P350 Screensaver timeout 0 0 60 Min
P351 Display backlight brightness 1 10 10
P360 Group heating element power 0 150 2000 W
P361 Coee boiler heating element power 0 1000 2000 W
P362 Services boiler primary heating element power 0 2000 5000 W
P363 Services boiler secondary heating element power 0 1000 3000 W
P364 Cup heater heating element power 0 200 500 W
P365 Power pump motor 0 330 500 W
P400 Cloud data sending duration 1 5 9999 s
P401 Period download data from the Cloud 1 5 250 s
