IE-SW-VL08M Series User’s Manual Featured Functions
3-7
Switch Subnet Mask
Setting Description Factory Default
Subnet mask of the
IE-SW-VL08M
Identifies the type of network to which the
IE-SW-VL08M is connected (e.g., 255.255.0.0
for a Class B network, or 255.255.255.0 for a
Class C network).
255.255.255.0
Default Gateway
Setting Description Factory Default
Default Gateway of the
IE-SW-VL08M
The IP address of the router that connects the
LAN to an outside network.
None
DNS IP Address
Setting Description Factory Default
1st DNS Server’s
IP Address
The IP address of the DNS Server used by your
network.
None
2nd DNS Server’s
IP Address
The IP address of the DNS Server used by your
network. The IE-SW-VL08M will try to locate
the 2nd DNS Server if the 1st DNS Server fails
to connect.
None
Global Unicast Address Prefix (Prefix Length: 64 bits)
Setting Description Factory Default
Global Unicast Address
Prefix
The prefix value must be formatted according to
RFC 2373 “IPv6 Addressing Architecture,”
using 8 colon-separated 16-bit hexadecimal
values. One double colon may be used in the
address to indicate the appropriate number of
zeros required to fill the undefined fields.
None
Global Unicast Address
Setting Description Factory Default
None Displays the IPv6 Global Unicast address. The
network portion of the Global Unicast address
can be configured by specifying the Global
Unicast Prefix and using a EUI-64 interface ID
in the low order 64 bits. The host portion of the
Global Unicast address is automatically
generated using the modified EUI-64 form of
the interface identifier (Switch’s MAC address)
None
Link-Local Address
Setting Description Factory Default
None The network portion of the Link-Local address
is FE80 and the host portion of Link-Local
address is automatically generated using the
modified EUI-64 from of the interface identifier
(Switch’s MAC address)
FE80: (EUI-64
form of the MAC
address)
