IE-SW-VL08M Series User’s Manual Featured Functions
3-33
connected to the Tail port as a backup path and the path is blocked, and Link down if there is no
connection.
Explanation of “Settings” Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring
Select this item to change to the Turbo Ring
configuration page.
Turbo Ring V2
Select this item to change to the Turbo Ring V2
configuration page.
Turbo Chain
Select this item to change to the Turbo Chain
configuration page
RSTP (IEEE
802.1W/1D)
Select this item to change to the RSTP configuration
page.
None Ring redundancy is not active
None
Role
Setting Description Factory Default
Head Select this switch as Head Switch
Member Select this switch as Member Switch
Tail Select this switch as Tail Switch
Member
Head Role
Setting Description Factory Default
Head Port Select any port of the switch to be the head port.
P
ort 4
P
ort 7
Member Port Select any port of the switch to be the member port.
P
ort 5
P
ort 8
Member Role
Setting Description Factory Default
1
st
Member port
Select any port of the switch to be the 1
st
member
port
Port 4
P
ort 7
2
nd
Member port
Select any port of the switch to be the 2
nd
member
port
Port 5
P
ort 8
Tail Role
Setting Description Factory Default
Tail Port Select any port of the switch to be the tail port.
P
ort 4
P
ort 7
Member Port Select any port of the switch to be the member port.
P
ort 5
P
ort 8
The STP/RSTP Concept
Spanning Tree Protocol (STP) was designed to help reduce link failures in a network, and provide
protection from loops. Networks that have a complicated architecture are prone to broadcast storms
caused by unintended loops in the network. Weidmueller Switch’s STP feature is disabled by default.
To be completely effective, you must enable RSTP/STP on every switch connected to your network.
