IE-SW-VL08M Series User’s Manual Featured Functions
3-13
the Ring Master. If you accidentally enable more than one IE-SW-VL08M to be the Ring Master,
these IE-SW-VL08M switches will auto-negotiate to determine which one will be the Ring Master.
NOTE
If you use the browser interface to enable the DIP switches (by un-checking the “Disable the Turbo
Ring DIP switch” checkbox), and then flip DIP switch 4 from ON to OFF, the Ring Ports and
Coupling Ports that were added to all VLANs will be restored to their previous software settings.
(For details, please refer to the “Using Virtual LANs” section of this manual).
System File Update: By Remote TFTP
The IE-SW-VL08M supports saving your configuration file to a remote TFTP server or local host to
allow other IE-SW-VL08M switches to use the same configuration at a later time, or saving the Log
file for future reference. Loading pre-saved firmware or a configuration file from the TFTP server or
local host is also supported for easy upgrading or configuration of the device.
TFTP Server IP/Name
Setting Description Factory Default
IP Address of the
TFTP Server
The IP or name of the remote TFTP server.
Must be set up before downloading or
uploading files.
None
Configuration Files Path and Name
Setting Description Factory Default
Max. 40
Characters
The path and file name of the device’s
configuration file on the TFTP server.
None
Firmware Files Path and Name
Setting Description Factory Default
Max. 40
Characters
The path and file name of the devices’s
firmware file.
None
Log Files Path and Name
Setting Description Factory Default
