IE-SW-VL08M Series User’s Manual Featured Functions
3-61
Email Warning Events Settings
NOTE: The user interface for the IE-SW-VL08M shows 8 ports.
Event Types
Event Types can be divided into two basic groups: System Events and Port Events. System Events
are related to the overall function of the switch, whereas Port Events are related to the activity of a
specific port.
System Event Warning e-mail is sent when…
Switch Cold Start Power is cut off and then reconnected.
Switch Warm Start The device is rebooted, such as when network
parameters are changed (IP address, netmask, etc.).
Power Transition (OnÆOff) The device is powered down.
Power Transition (OffÆOn) The device is powered up.
Configuration Change Activated Any configuration item is changed.
Comm. Redundancy Topology
Changed
If any Spanning Tree Protocol switches have changed
their position (applies only to the root of the tree). If
the Master of Turbo Ring has changed or backup path
is activated.
Authentication Failure An incorrect password is entered.
Port Event Warning e-mail is sent when…
Link-on The port is connected to another device.
Link-off
The port is disconnected (e.g., the cable is pulled out,
or the opposing device shuts down).
Traffic-Overload
The port’s traffic surpasses the Traffic-Threshold for
that port (provided this setting is Enabled).
