18 Assembly
EN
2. Screw the top part of the bubble humidifier onto
the corresponding threaded connection of the
Oxygen MODULE or the Combi MODULE by
hand.
3. Fill the bottom part up to the mark with distilled
water (aqua dest.) and screw the tank back on.
4. Push the tube for the breathing station onto the
outlet stub of the bubble humidifier.
4.6 Assembling the OMNIVAC
secretion aspiration system
The OMNIVAC secretion aspiration system is
required for aspiration using the Suction MODULE or
the Combi MODULE.
1. Screw the holder for the secretion aspirate
bottles to a suitable point.
