4.7 Assembling the CPAP valve
1. Connect the CPAP valve to the CPAP module
using the connecting tubes.
Ensure that the tubes are guided cleanly so that
they do not impede one another.
2. Perform a function check (see “12.6 Checking
oxygen flow” on page 47).
O
2
Oxygen
outlet
Pressure
measurement
tube
