62 Technical data
EN
16.3 Oxygen output, inhalation
Tolerance ±10 %
16.4 Aspiration performance
Maximum performance
Maximum performance for the Combi MODULE and
the Suction MODULE depend on the inlet pressure of
the oxygen supply in operation. The measurements
relate to an aspirate bottle with a capacity of 2 liters.
Tolerance ±10 %. If the bacteria filter is used,
aspiration performance is reduced as a function of
humidity by approx. 1 to 3 l/min.
Inlet pressure
in operation
2.7 bar 3.0 bar 3.5 bar 6.0 bar
Max. O
2
output
11 l/min 12 l/min 15 l/min 15 l/min
Inlet pressure
p2
Max.
vacuum
Max. aspiration
performance
O
2
consumption
2.7 bar – 0.40 bar 8.4 l/min 9.3 l/min
3.0 bar – 0.44 bar 8.6 l/min 10.1 l/min
3.5 bar – 0.53 bar 8.8 l/min 11.4 l/min
4.0 bar – 0.58 bar 9.0 l/min 12.2 l/min
4.5 bar – 0.60 bar 9.0 l/min 14.0 l/min
5.0 bar – 0.60 bar 9.0 l/min 15.0 l/min
5.5 bar – 0.60 bar 8.7 l/min 17.0 l/min
6.0 bar – 0.60 bar 8.5 l/min 19.0 l/min
