Technical data 63
EN
Suction MODULE aspiration performance
The aspiration performance of the Suction MODULE
at any particular time depends on the vacuum set.
The measurements relate to an aspirate bottle with
a capacity of 2 liters.
Tolerance ±10 %. If the bacteria filter is used,
aspiration performance is reduced by approx. 1 to
3 l/min.
Vacuum set
Aspiration
performance
O
2
consumption
Required
inlet pressure
p2
- 0.2 bar 5.3 l/min 6.5 l/min 2.7 – 6 bar
- 0.3 bar 6.5 l/min 7.7 l/min 2.7 – 6 bar
- 0.4 bar 8.4 l/min 9.3 l/min 2.7 – 6 bar
- 0.5 bar 8.3 l/min 10.5 l/min 3.5 – 6 bar
- 0.6 bar 9.0 l/min 14.0 l/min 4.5 bar
