28 EN RESCUE-PACK Plus
WM 66531 2023-01
6 Disassembly
6.4 Disassembling
charging interface
from LIFE-
BASE 1NG XS
6.5 Disassembling
charging interface
port
If the crimp connector is difficult to loosen:
Use long-nose pliers.
2
1
2
