Weinmann RESCUE-PACK Plus - Attaching shoulder straps; Fitting charging interface port

WM 66531 2023-01
RESCUE-PACK Plus EN 37
8 Assembly
8.2 Attaching shoulder
straps
8.3 Fitting charging
interface port
Note during assembly:
• The negative pole (–) of the plug must
be at the top and the positive pole (+) at
the bottom.
• The sealing ring (a) must be placed
directly on the outer wall of the
emergency backpack.
1
2
Pole Cable color
–Black
+Red
a
1
