9 Faults rectification
The following faults must be rectified only by qualified personnel:
Fault codes Cause Rectification
65h First detailed fault code: uCheck freedom of movement of air damper and/or
00h angle drive and gas butterfly valve.
Tolerance fault air stepping motor, gas uReplace the stepping motor.
stepping motor or VSD uCheck the VSD or blower, replace if necessary.
First detailed fault code: uCheck freedom of movement of air damper and/or
01h angle drive and gas butterfly valve.
Tolerance fault air or gas stepping motor uReplace the stepping motor.
First detailed fault code: uCheck freedom of movement of gas butterfly valve
02h Tolerance fault gas stepping motor uReplace the stepping motor.
or VSD uCheck the VSD or blower, replace if necessary.
First detailed fault code: uCheck freedom of movement of gas butterfly valve
03h uReplace the stepping motor.
Tolerance fault gas stepping motor
First detailed fault code: uCheck freedom of movement of air damper and/or
04h angle drive and gas butterfly valve.
Tolerance fault air stepping motor uReplace the stepping motor.
or VSD uCheck the VSD or blower, replace if necessary.
First detailed fault code: uCheck freedom of movement of air damper and/or
05h angle drive and gas butterfly valve.
Tolerance fault air stepping motor uReplace the stepping motor.
First detailed fault code:
07h
Time run out during speed standardization uPress [+] key within 20 sec. during speed std.
Time in setting mode run out uPress key within 30 min. in setting mode.
Plugs or stepping motors for gas uChange-over the plugs or stepping motors.
and air mixed up
A2h Safety circuit is open uCheck safety circuit.
A4h Reverse voltage valve 1 uCheck the wiring to the double gas valves.
A5h Reverse voltage valve 2 uCheck the wiring to the double gas valves.
A6h Flame simulation/extraneous light uFind and eliminate extraneous light source.
uCheck ionization electrode.
A7h No flame signal after safety time uSet the ignition electrode.
uCheck the ignition unit, replace if necessary
uCheck the ionization electrode and cable, replace if
necessary.
uCheck the gas valves actuators (solenoids or
motors), replace if necessary.
uCheck the mixing pressure, reduce if necessary.
uCheck the burner settings.
uReplace the combustion manager (see Ch 8.12).
83055116 • 1/2016-05
Installation and Operating Instructions
G
as burner WG20.../1-C ZM-LN (W-FM 25)
