Weishaupt WM-L20/2-A R User Manual

Installation and operating instruction
Oil burner WM-L20/2-A R (W-FM100/200)
3 Product description
83252902 1/2019-09 La
14-84
3.4.2 Electrical data
Burner control
Mains voltage / mains frequency 230 V/50 Hz
Consumption at start max 295 W
Consumption during operation max 185 W
Power consumption max 1.6 A
Internal unit fuse T6.3H, IEC 127-2/5
External fuse max 16 AB
Burner motorWM-D112/140-2/3K5
Efficiency [η] 87.7 % (at 100% load)
88.8% (at 75% load)
87.4% (at 50% load)
Efficiency class IE3
Year of manufacture see name plate
Manufacturer Max Weishaupt GmbH
Max-Weishaupt-Straße 14
88475 Schwendi
District Court Ulm HRB
640125
Type WM-D112/140-2/3K5
Poles 2
Nominal load 3.5 kW
Mains frequency 50 Hz
Mains voltage 380 … 415 V
Speed 2940 min
-1
(rpm)
Disposal see Ch. 2.3 Disposal
Design height 1000 m
Ambient temperature -15 … +40°C
Coolant temperature –
Operating temperature max 40°C
Explosion protection –
Consumption max 4.1 kW
Power consumption max 7.2 A
External fuse direct start
External fuse YΔ start
External fuse frequency converter mounted
External fuse frequency converter separate
25 A
16 A
20 A
16 A

Weishaupt WM-L20/2-A R Specifications

General

Brand	Weishaupt
Model	WM-L20/2-A R
Category	Burner
Language	English
