Installation and operating instruction
Oil burner WM-L20/2-A R (W-FM100/200)
4 Installation
83252902 1/2019-09 La
20-84
4.2 Check rating
The burner as delivered has been:
pre-sized for a specific oil throughput,
equipped with an oil nozzle type -w- K3 S1 50°.
The exact details are documented on the burner data sheet.
Pump pressure setting
30 bar
Determine exact oil throughput at oil meter or by weighing.
Nozzle selection table -w- K3 S1 50°
The following minimum capacity values are achieved with an oil quantity regulator
setting of 90°.
Burner capacity [kW] at pump pressure
Nozzle size [kg/h] 20 bar 22 bar 24 bar 26 bar 28 bar 30 bar
90 851 893 934 976 1017 1059
100 898 941 984 1027 1070 1113
110 987 1035 1083 1130 1178 1226
120 1095 1147 1200 1252 2305 1357
130 1214 1272 1330 1389 1447 1505
140 1297 1359 1421 1483 1545 1607
150 1416 1483 1549 1616 1682 1749
160 1505 1576 1648 1719 1791 1862
170 1624 1700 1776 1853 1929 2005
180 1708 1788 1867 1947 2026 2106
