Weishaupt WM-L20/2-A R - Removing Fan Wheel

Installation and operating instruction
Oil burner WM-L20/2-A R (W-FM100/200)
9 Servicing
83252902 1/2019-09 La
56-84
9.11 Removing fan wheel
Observe notes on servicing [ch.9.1].
A tamper proof screw must be used when installing the fan wheel.
Remove screw1.
Remove fan wheel with fan wheel puller from motor shaft.
1
