Weishaupt WM-L20/2-A R User Manual

Installation and operating instruction
Oil burner WM-L20/2-A R (W-FM100/200)
13 Spares
83252902 1/2019-09 La
73-84
Pos. Description Order No.
3.37 Collar screw GP-BDBS-L15-G½-ST 450 651
3.38 Sealing ring A27 x 32 x 2 DIN 7603 Cu 440 039
3.39 Threaded socket DN 20 M30 x 1.5 x M26 x1.5 111 782 06 027
3.40 Oil hose DN20 1000 lg identification black 491 034
3.41 Threaded socket DN 20 M30 x 1.5 x G1 112 151 00 057
3.42 Sealing ring A33 x 39 x 2 DIN 7603 Cu 440 032
3.43 Pipe elbow DN 20 M30x1.5xM30x1.5 x G⅛ 453 251
3.44 Threaded socket DN 20 M30 x 1.5 x G½ 112 654 00 017
3.45 Vacuum gauge -1+9 bar for TA pump 210 204 06 192
3.46 Pressure gauge 0 to 40 bar for TA pump 210 204 06 182
3.47 Pump coupling 54.3 x D 35 218 324 09 012
3.48 Universal joint 111 151 09 017
3.49 Coupling centre piece 235 mm 211 402 09 012
3.50 Pressure hose DN 6 650 mm* 210 201 10 012
3.51 Nut M16 x 1.5 * 210 104 10 087
* Only in conjunction with combustion head extension.
