Rotary indexing ring NR
Product description
3.5 Mounting positions
NOTICE
OIL LOSS OR DRY RUN DUE TO INCORRECT MOUNTING POSITION
Failure to follow these instructions can result in equipment damage.
■
Verify that you only use the standard mounting positions approved in these
mounting instructions.
Permissible standard mounting positions
The product may only be mounted as shown below.
Axis of rotation
vertical
Axis of rotation
horizontal (on-
ly product type
NR0750Z)
3.6 Drive positions
The product is delivered with the drive position specified in the order.
Standard version with motor at the bottom
Drive housing inside by 90°
Mounting instructions_062019_1.0_en
15 / 62
