Rotary indexing ring NR
Maintenance
15 Maintenance
15.1 Maintenance plan
When Activity
■
Clean all surfaces of the product, see
chapter 14.1
■
Verify all screw connections of the product for
correct tightening torque
At least once per year
■
Verify correct connection of all plug
connections
At least every 2 million cycles or once per year
■
Inspect the toothed belt, see chapter 15.4
■
Replace the toothed belt, see chapter 15.5If required
■
Replace the motor, see chapter 15.3
15.2 Lubricant
The product features lifetime lubrication.
Refer to the documentation of the manufacturer for information on the lubricants used; see applicable
documents.
15.3 Replacing the motor
DANGER
ELECTRIC SHOCK CAUSED BY LIVE PARTS
Failure to follow these instructions will result in death or serious injury.
■
Disconnect the mains supply voltage before performing the work and ensure that
it cannot be switched on.
■
Verify that no hazards can be caused by electrically conductive objects.
■
Verify that all cables for the power supply are disconnected from power.
WARNING
UNANTICIPATED MOVEMENT OF THE ROTARY RING/THE ROTARY RING
The gear is not self-locking. When the drive and the output flange/rotary ring are
decoupled, the output flange/rotary ring can move.
Failure to follow these instructions can result in death, serious injury, and
equipment damage.
■
Block or safeguard the output flange/rotary ring in such a way that a movement
of the output flange/rotary ring is safely prevented before releasing the holding
brake or decoupling the drive and the output flange/rotary ring.
48 / 62
Mounting instructions_062019_1.0_en
