Rotary indexing ring NR
Technical data
4.6 Load data
Characteristic Unit Value
NR0750Z NR1100Z NR1500Z NR2200Z
Permissible axial force during
movement
N 3500 6000 8000 15000
Permissible moment of tilt dur-
ing movement
Nm 750 2500 3200 4500
Permissible radial force during
movement
N 7000 12000 16000 30000
Maximum acceleration torque at
output flange
Nm 1800 3400 5000 13000
Total gear ratio - 90/180 88 112 220
Maximum output speed of rota-
tion
1/min 22.5 22.5 18 9
Friction torque drive side at 10
°C
Nm 4 5 5 6
Mounting instructions_062019_1.0_en
23 / 62
