Rotary indexing ring TR
Product description
3.5 Mounting positions
NOTICE
OIL LOSS OR DRY RUN DUE TO INCORRECT MOUNTING POSITION
Failure to follow these instructions can result in equipment damage.
■
Verify that you only use the standard mounting positions approved in these
mounting instructions.
Permissible standard mounting positions
The product may only be mounted as shown below.
The product types TR0750A, TR1100A,
TR1500A and TR2200A may only be mounted
horizontally.
Normal / MP 1
14 / 79
Mounting instructions_062019_4.0_en
