Rotary indexing ring TR
Technical data
Product type Type Manufacturer
100L/12 B14 F160 0.37 kW BRE230V 20 Nm
100S/4 B14 P160 2.20 kW BRE024V 20 Nm Thermoklick
090V/8 B14 F140 0.75 kW BRE024V Thermoklick
090V/8 B14 F140 0.75 kW BRE230V
4.3 Holding brake
Refer to the documentation of the manufacturer for the technical data of the holding brake; see
applicable documents.
Characteristic Value
Supply voltage holding brake See order confirmation
Integrated into motor
(motor size)
Voltage Input power at 20°C Power coil at 20°C
71 and 80 24 V DC 1.25 A 30 W
71 and 80 205 V DC 0.15 A 30 W
90 and 100 24 V DC 1.25 A 30 W
90 and 100 205 V DC 0.15 A 30 W
4.4 Inductive sensor
Refer to the documentation of the manufacturer for the technical data of the inductive sensor; see
applicable documents.
Depending on the order, the following inductive sensor is installed:
Product type Type Manufacturer
TR0750A NBB2-8GM40-E2-V3
3RG4011-7GB33-PF
TR1100A, TR1500A,
TR2200A
NBB4-12GM30-E2-V1
NBB4-12GM30-E0-V1
Pepperl+Fuchs-Gruppe
4.5 DRIVE-CLiQ encoder (optional)
Refer to the documentation of the manufacturer for the technical data of the optional encoder; see
applicable documents.
Type Manufacturer
6FX2001-5FD25-1AA0 SIEMENS AG
