Rotary indexing ring TR
Mounting
5. Mount the cover by means of the screws [5].
6. Remove all tools and equipment.
7. Perform a test run.
8.6 Mounting additional components
WARNING
IMPROPERLY FASTENED PARTS
Failure to follow these instructions can result in death, serious injury, and
equipment damage.
■
Verify that the supporting structure and/or the frame and/or the mounting surface
for fastening the product are sufficiently rated to withstand all static and dynamic
loads and forces during operation.
■
Verify that the fastening parts comply with the specifications indicated and that
they are sufficiently rated for all load conditions during operation.
CAUTION
INCORRECT MOUNTING OF ADDITIONAL COMPONENTS
Failure to follow these instructions can result in injury or equipment damage.
■
Only mount components to the rotary ring/stationary plate that are approved by
the manufacturer.
■
Only use existing holes for mounting additional components to the rotary ring/
stationary plate.
■
After mounting, do not drill holes into the rotary ring/stationary plate.
■
Do not perform welding work at the rotary ring/stationary plate.
NOTICE
BLOCKING OF THE PRODUCT DUE TO EXTRANEOUS OBJECTS
Mounting an additional indexing plate or an attachment plate creates a gap through
which extraneous objects can get into the product.
Failure to follow these instructions can result in equipment damage.
■
Mount a suitable lip seal between the rotating plate and the stationary plate.
■
Verify that the lip seal does not collide with the existing holes.
36 / 79
Mounting instructions_062019_4.0_en
