Page #17 background imageLoading...
Page #17 background image
Rotary indexing ring TR
Technical data
4 Technical data
4.1 General
Characteristic Unit Value
TR0750A TR1100A TR1500A TR2200A
Direction of rotation - Left, right, or alternating
Recommended maximum diam-
eter of attachment
mm Approxi-
mately 1500
Approxi-
mately 2200
Approxi-
mately 3000
Approxi-
mately 4400
Indexing accuracy arcsec 36 (± 18) 36 (± 18) 30 (± 15) 24 (± 12)
Maximum axial runout of output
flange
mm at Ø 635
0.05
at Ø 945
0.06
at Ø 1275
0.08
at Ø 1990
0.08
Maximum axial runout including
the rotary ring
mm at Ø 750
0.07
at Ø 1100 at Ø 1500
0.1
at Ø 2200
0.15
Maximum radial runout of the
output flange
mm 0.03 0.04 0.04 0.05
Maximum error in parallelism
between output flange and
mounting surface of housing
mm 0.05 0.06 0.08 0.08
Weight (without rotary ring) kg 230 310 400 950
Weight with packaging kg See bill of delivery
Sound pressure dB(A) < 70
Lubricant - Shell Omala S2 G 680
Lubricant volume l 2 2.8 3 5.2
The specified axial and radial runout tolerances are only reached with precise support surfaces.
4.2 Motor
Refer to the documentation of the manufacturer for the technical data of the motor; see applicable
documents.
Characteristic Unit Value
TR0750A TR1100A TR1500A TR2200A
Voltage V 230 / 400
Frequency Hz 50
Product type Type Manufacturer
071L/4 B14 P105 0.37 kW BRE024V 10Nm Thermoklick
071L/4 B14 F105 0.37 kW BRE230V 10Nm Thermoklick
071L/6 B14 P105 0.25 kW BRE024V 10Nm Thermoklick
TR0750A
071L/6 B14 F105 0.25 kW BRE230V 10Nm Thermoklick
Končar – MES d.d.
Mounting instructions_062019_4.0_en
17 / 79
