Rotary indexing ring TR
Cleaning
WARNING
HOT SURFACES
The temperature of the motor and the holding brake can exceed 100 °C during
operation.
Failure to follow these instructions can result in death, serious injury, and
equipment damage.
■
Avoid unprotected contact with hot surfaces.
■
Do not allow flammable or heat-sensitive objects in the vicinity of hot surfaces.
■
Before performing work on the motor or the holding brake, verify that you wait for
a sufficient period of time to allow such parts to cool down to a temperature that
allows for safe contact.
For cleaning of electrical components and additional components, respect the instructions in the
documentations of the manufacturer; see applicable documents.
Use the following cleaning agents for cleaning the product:
Component Cleaning agents
Housing
Rotary ring
Raised ring
Stationary plate
Neutral, mildly alkaline
Motor Dry cleaning
1. Remove fine impurities and dust with a dry, lint-free cloth.
2. Use a wet cloth and a neutral, mildly alkaline cleaning agent to remove stains on the housing, the
rotary ring, the raised ring, the stationary plate and/or on the output flange.
3. Dry the cleaned areas.
4. Remove all equipment from the product.
5. Restore the readiness for operation of the product.
Mounting instructions_062019_4.0_en
51 / 79
