CMP100 User Guide
18
After batch addition, you can now modify the parameters for each service.
After configuring, you can create a backup file configuration by clicking .
Loading the backup file can be done by clicking .
When using the UDP protocol, you can output 100 services to unlimited number of
terminals with OMP150100 and 150 services to unlimited number of terminals with
OMP150200. To do this, you need to check the box . Take note
that the protocol, IP address and IP port of the input should be same with those of the
output. To implement this, it is also required for the source, the OMP150, and the STB in
the same network.
After you enable the “Send channel list only”, the output bitrate should show 0kbits/s,
indicating that the Service output is normal.
