CMP100 User Guide
54
Equilibrium
Server
Cache Server
Main Server
App
Ethernet: eth2
IP Adress: 10.10.1.110
Ethernet: eth2
IP Adress: 10.10.1.113
Ethernet: eth2
IP Adress: 10.10.1.112
Communication Topology
(Communication Port Settings)
Ethernet: eth3
IP Adress: 10.200.1.190
Ethernet: eth3
IP Adress: 10.200.1.193
Ethernet: eth3
IP Adress: 10.200.1.200
Business Topology
(Signal Port Settings)
Main Server
Communication Topology
This shows the communication topology of the servers/nodes. The ethernet number with
assigned IP address is shown here as defined in 3.9.1 Node Settings. Each
server/node has designated ethernet port for communication with other nodes. Please
refer to 3.10.1 Network for configuration of ethernet ports.
