7.4. Analog
The menu item “A2 Analog” is present for the Sensor OPT2011 if pin 2 is set as an analog output.
Analog Settings of the analog output
Mode U/I
Teach-In
At 0 V
At 10 V
At 4 mA
At 20 mA
3 Back
7 Run
Mode U/I: Set analog output to a voltage or current output.. The analog output
can be set as a voltage output by pressing the “U” key. and as a out-
put by pressing the “I” key.
Teach-In: Teach-In of the start and end of the measurement range, depending
on the U/I mode set. By pressing the “T” key, the current distance is
assigned the value 4 mA or 0 V. The value 20 mA or 10 V can be as-
signed to a distance by navigating downwards. The smallest measure-
ment range that can be set is 50 mm.
At 0 V: Distance at 0 V (visible in U mode) The distance assigned to the value
0 V can be recalibrated by pressing the “+” key or the “–” key.
At 10 V: Distance at 10 V (visible in U mode) The distance assigned to the
value 10 V can be recalibrated by pressing the “+” key or the “–” key.
At 4 mA: Distance at 4 mA (visible in I mode) The distance assigned to the value
4 mA can be recalibrated by pressing the “+” key or the “–” key.
At 20 mA: Distance at 20 mA (visible in I mode) The distance assigned to the
value 20 mA can be recalibrated by pressing the “+” key or the “–” key.
7.5. Display
Display Adjusting the display device
Mode
Rotate
Intensity
3 Back
7 Run
Mode: Select display mode (see chapter 7.5.1)
Rotate: Rotate display by 180°.
The display is rotated by 180° by pressing the  key. The rotation is
canceled by pressing this key again.
Intensity: Set the display intensity (see chapter 7.5.2)
7.5.1. Display Mode
Mode Select display mode
 Switch
 Analog
3 Back
7 Run
Switch: The statuses of the individual inputs and outputs, and the measure-
ment value in mm are shown in the display.
Analog: The analog output value and the measurement value in mm are shown
in the display.
