7.5.2. Display Intensity
Intensity Set the display intensity
Min
Normal
Max
Power save
Screensaver
3 Back
7 Run
Min: The intensity of the display is set to a minimum value.
Normal: The intensity of the display is set to a medium value.
Max: The intensity of the display is set to a maximum value.
Power save: The display switches off after one minute without a button being
pressed and automatically switches back on when a button is
pressed.
Screensaver: The colors of the display are inverted every minute.
7.6. Expert Menu
Different menu items and sub-items appear in the menu, depending on whether the Expert Menu is “On” or
“Off”. The Expert Menu is off in the delivery state. The menu is thereby shorter and easier to use. If the existing
menu items are not sufficient for the application solution, the Expert Menu can be switched on in order to use
the full scope of Sensor functions.
Expert Menu Switch Expert Menu on or off
OFF
ON
3 Back
7 Run
OFF: The Expert Menu is switched off and only a few menu items are visible.
ON: The Expert Menu is switched on and all menu items are visible.
7.7. Filter
The filter (filter size) is the number of measurement values over which the Sensor takes an average. The larger
the selected filter, the slower the response time of the Sensor becomes when there is change of the measure-
ment values. A larger filter improves the reproducibility of the Sensor.
Note: The menu item is only visible if Expert Menu “On” has been set.
Filter Number of values for averaging
1
2
5
10
20
50
100
200
500
3 Back
7 Run
If 1 is selected, each measurement value is output directly without averaging.
Whenever a value greater than 1 is selected, the Sensor takes an average over
the selected number of x measurement values, which is output every 2 ms at the
output.
