4. Device Features
Order Number OPT2011
Working Range 50...3050 mm
Measuring Range 3000 mm
Reproducibility 1 mm
Linearity Deviation (200…3050 mm) 7 mm
Linearity Deviation (50…200 mm) 15 mm
Switching hysteresis 3…20 mm
Light Source Laser light (red)
Laser Class 1
Supply Voltage 18…30 V DC
Current Consumption (Ub = 24 V) < 70 mA
Switching Frequency 250 Hz
Response Time 2 ms
Temperature Drift (−10° < Tu < 50°) < 0,2 mm/K
Temperature Drift (Tu < −10°) < 0,4 mm/K
Temperature Range −40 °C…50 °C
Voltage Drop < 2,5 V
Switching Output/Switching Current 100 mA
Short Circuit Protection yes
Reverse Polarity and Overload Protection yes
Protection Class III
Protection IP68
Connection
M12 × 1; 4-pin
Measuring Range:
The Sensors’ measuring range is determined by object remission.
Maximum range of up to 3 m on white (90 % remission)
up to 3 m on grey (18 % remission)
up to 2 m on black (6 % remission)
Light Spot Diameter
Working Distance 0 3 m
Light Spot Diameter 5 mm 9 mm
