Meaning of the menu items:
3Back: one level higher in the menu.
7Run: switch to delay mode.
Switch to the configuration menu by pressing any key.
Note:
If no settings are adjusted in the configuration menu for a period of 30 s, the Sensor is automatically returned to
the read-out view. The Sensor accesses the last used menu view when a key is once again activated.
If a setting is adjusted, it becomes active when the configuration menu is exited.
Important:
Do not use any sharp objects to press the keys when configuring settings, because they might otherwise
be damaged.
6.2. Default Settings
OPT2011
Pin Function
E/A 1 Switching output
E/A 2 Analog output
Outputs
Teach Mode T Foreground
Switching threshold 1000 mm
Switching Hysteresis 12 mm
Window Size 50 mm
PNP/NPN PNP
NO/NC NO
On-Delay 0 ms
Off-Delay 0 ms
Impulse 0 ms
Analog
U/I I
4 mA 50 mm
20 mA 3050 mm
Display
Mode Switch
Intensity Screensaver
Expert menu
Off
Filter
5
Laser
On
Language
English
Password
Enable Off
