2.4
Main Catalyst Silencer
Band Clamp
Oval End
Rear Mounting Bracket for Long Silencer will fit level
to outside of chassis tubes (Later Chassis do not
have the flat plates with swaged holes)
Round End of Silencer
with Catal
y
st Fitted
Step 3 ; Rear Pipe and Small Silencer
The later exhaust systems have a loose section of pipe that goes between the two silencers to
make fitting slightly easier. This is the section that goes through the rear Wing Post if you have
fitted one.
