1.9
TORQUE CHART
Settings in Pounds Feet and Newton Metres: ft-lbs. Nm
Three Way Brake Pipe Unions 5 7
Rear Brake Caliper Mounting Bolts (Steel) 40 54 *
Steering Rack Mounting Bolts to Chassis 20 27
Track Rod End Nuts to Steering Arm 28 38
Wishbone Securing Bolts to Chassis 35 40
Lower Ball Joint Securing Bolts to Wishbone 22 34
Lower Ball Joint Nut to Upright Block 28 38
Top Ball Joint Nut to Upright Block 25 34
Steering Column Upper Mounting Bolts 20 27 **
Steering Column Shaft Couplings 20 27 **
Steering Column Securing Clamp 28 38 **
Front Brake Caliper Mounting Bolts (Steel) 40 54 *
Shock Absorber to Chassis Mounting Bolts 30 40
Handbrake Mounting Bolts 22 30
Seat Belt Mounting Bolts 26 35
Steering Wheel Nut 35 47
Wheel Nuts (Rimstock) 65 90
Differential Unit Bolts to Chassis (SEi) 30 40
Rear Brake Caliper Mounting Bolts (SEi) 35 47 *
Drive Shaft Hub Nut (SEi) 250 340
Oil Pressure Switch 9 12
Neutral Switch 9 12
Sprocket Retaining Bolt (Modified Cap Head) 104 54 *
6mm Bolts 9 12
8mm Bolts 18 24
9mm Bolts 20 27
10mm Bolts 28 39
Sump Pan Retaining Bolts 9 12
(In sequence as instructed)
