2.5
Step 4 ; Seat Belt Mountings
The seat belts are to be fixed as shown below
Outer Lower Seatbelt Mounting
The two outer lower
seatbelt straps are fixed
using two special 7/16
UNF thin headed bolts
and a 7/16 washer.
Centre Tunnel Mounting
This centre tunnel monuting is one 7/16 unf x 4 inch long bolt staight through,with nyloc and
washers. The top belt mountings are 4 x 7/16 unf bolts with special thin nyloc nuts and plain
washers.
