4.15
DASHBOARD WIRING LOOM DETAILS
CONNECTION LOOM CONNECTOR TYPE LOOM WIRE COLOURS NOTES
MAIN LOOM 13 WAY BLACK CONNECTOR
BLOCK – MALE
13 WAY BLACK CONNECTOR
BLOCK – FEMALE
8 WIRES
11 WIRES
PRE-WIRED
PRE-WIRED
IGNITION RELAY EARTH FEED BARE WIRES 2 BLACK CUSTOMER TO FIT TO MASTER SWITCH
WARNING LAMP CONNECTIONS BARE WIRES 8 WIRES PAIRED AS FOLLOWS:
BLACK ; RED / ORANGE
ORANGE ; GREEN
BLACK ; GREEN / WHITE
BLACK ; GREEN / RED
CAPILLARY CLOCK ILLUMINATION
NEUTRAL LAMP
OFF SIDE INDICATOR
NEAR SIDE INDICATOR
FUEL GAUGE 3 WAY BLACK CONNECTOR BLOCK GREEN ; BLACK ; GREEN / BLACK PRE-WIRED
TACHOMETER 3 WAY BLACK CONNECTOR BLOCK GREEN - 1 PAIR ; BLACK – 1 PAIR ;
WHITE / BLACK
PRE-WIRED
AUXILLARY 2 WAY BLACK CONNECTOR BLOCK BLACK – 1 PAIR ; GREEN – 1 PAIR PRE-WIRED
REVERSE SWITCH 2 FEMALE SPADE CONNECTORS ORANGE / ORANGE/BLACK PRE-WIRED
HORN 2 FEMALE SPADE CONNECTORS PURPLE ; PURPLE / BLACK PRE-WIRED
OFF SIDE INDICATOR CONNECTOR BLOCK BLACK ; GREEN / WHITE PRE-WIRED
INDICATOR TIMER UNIT PRE-WIRED PLUG VARIOUS TIMER UNIT IS A SEPARATE ITEM TO THE LOOM
IGNITION FEED BARE WIRES 2 WHITE CUSTOMER TO FIT TO IMMOBILISER SWITCH
HANDBRAKE WARNING LAMP 2 FEMALE SPADE CONNECTORS BLACK ; BLACK/ WHITE PRE-WIRED
DASH’ SUB-LOOM CONNECTORS 7 WAY WHITE CONNECTOR &
5 WAY WHITE CONNECTOR
VARIOUS PRE-WIRED
HAZARD WARNING SWITCH PRE-CONNECTED VARIUS PRE-WIRED
RELAYS CONNECTOR RAIL VARIOUS 3 RELAYS & 1 FLASHER UNIT
