8-1
Chapter 8 Technical Data
Section 8-1- Mechanical
Dimensions (H x W x D) 21 x 16 x 6 in.
Weight 40 lb.
Finish Red
Enclosure Construction Type 0.050” steel
Mounting Indoor surface mount
Wiring Entry Top and bottom knockouts (3/4”, 1”)
Door Lock Standard Wheelock key-lock
PC Boards 1 Mother Board (SCDC)
1 Power Supply (DCPS)
1 Digital Voice Module (MDX-2)
1 Amplifier Module
Section 8-2 – Environmental
Operating Temperature 0 to 49 °C (32 to 120 °F)
Storage Temperature -20 to 70 °C (-4 to 158 °F)
Humidity, Non-condensing
85±5% at 30±2 °C (86 ± 4 °F)
Section 8-3 – Electrical
Input
Input Voltage 120VAC, 2.50A, 60Hz
220VAC, 1.25A, 50Hz for Export
Models
Battery Current Calculations
The current draw of the Single Circuit SAFEPATH
®
Panel is determined by the configuration being
utilized. Section 3-7 Battery Care and Battery Backup Calculation will assist you in developing the current
requirements.
Automatic Activation
Dry contact inputs or use of NACIM to activate from a NAC.
