Wheelock SAFEPATH SCSP-15SP User Manual

8-2
Outputs
Visual Notification Appliance
Output
1 output circuit. 2.0 amps at 24VDC
per zone. Supervised.
Central Amplified Audio Output 1 output circuit.
Selectable 25, 70.7 volt output at
40W or 80W max, or 100 volt
(export) at 80W. (Depending on
amplifier configuration). Supervised.
Amplified Speaker Audio
Output
1 output circuit, 15 Ohms,
-5dBm output max (when
configured with a SALL-15S).
Supervised
Amplified Speaker Power
Output
1 output circuit. 2.0 amps at 24VDC
(when configured with a SALL-15S).
Supervised.
Trouble Audible Output
0.100 amps at 24VDC. Non-
Supervised.
Status Contact
Form C contact normally energized.
Contacts transfer during trouble: 0.5
amps at 24VDC max, resistive load.
Non-Supervised.
Alarm Contact
Form C contact normally de-
energized. Contact transfers during
alarm: 0.5 amps at 24VDC max,
resistive load. Non-Supervised.
Table 8-1 Outputs
WARNING: DO NOT EXCEED THE RATINGS OF ANY STATUS CONTACT. EXCEEDING THE
RATINGS MAY CAUSE THE RELAY TO FAIL AND PREVENT A TROUBLE
CONDITION FROM BEING INDICATED.
DO NOT EXCEED THE RATINGS OF THE ALARM CONTACT. EXCEEDING THE
RATING MAY CAUSE THE RELAY TO FAIL AND PREVENT MESSAGES FROM
BEING PLAYED.
Wiring Connections
Screw terminals Accept #12 to #22 AWG
