Wheelock SAFEPATH SCSP-15SP User Manual

9-17
Section 9-10 - Auxiliary Input Module (AIM-3)
Wheelock, Inc. Part Number: 107387
The Auxiliary Input Module (AIM-3) is an outboard module for use with the SAFEPATH
®
Panels to expand
the number of optional Remote Microphone Stations from one to three. It also has the capability of using
one of the Remote Microphone Inputs to connect to a telephone system page port. See Figure 9-10 on
Page 9-18.
Additional information is available on the AIM-3 Installation Instruction Sheet P83667.
Electrical
Input Voltage 24VDC
Input Current 100 mA Telephone Page
60 mA RMS Page
40 mA Standby
Audio Input 1Vrms
Dimensions (H x W x D
)
13.0” x 7.6” x 2.15” (33cm x 19.4cm x 5.4cm)
