2
2. Using Table 2, calculate total
STROBE CURRENT
.
3. For SAA Series Amplifier Modules, use Table 2 and calculate
total
SPEAKER WATTAGE
.
4. For SALL-15S Module, use Table 2 and calculate total "
SPKR AMP
"
current.
5. SAA Series Modules,calculate the Alarm Current
Module using the total
SPEAKER WATTAGE
from Step 3 and
Table 3-7 in this manual.
6. In Table 3, using Table 3-5, list all alarm currents of Modules installed.
Table 3
Alarm Total
Module Qty Current Alarm Current
SCSP-PS 1 0.150 0.150
MDX-2 1 0.090 0.090
7.
alculate the
Total Alarm Current
in Table 3.
8. Add Steps 2, 4, 5, and 7 together as appropriate.
NOTE: THE MAXIMUM CURRENT OUTPUT IN ALARM CONDITION IS 6 AMPS.
9. Divide Step 8 by the appropriate value for Alarm Time in Amp Hours.
5 minutes of Alarm - divide Step 8 by 12
15 minutes of Alarm - divide Step 8 by 4
TOTAL ALARM CURRENT IN AMP HOURS
BACKUP BATTERY REQUIREMENT
1. Enter results
rom
Standby Current
section.
2. Enter results
rom
Alarm Current
section.
3. Add Steps 1 and 2 together, enter total
4. Multiply Step 3 by 1.25 for Minimum Backup Battery requirement.
Ampere Hours
