3-6
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
REMOVING AN INDICATOR LIGHT
CAUTION: When you work on the electric
range, be careful when handling the sheet
metal parts. Sharp edges may be present, and
you can cut yourself if you are not careful.
WARNING
1. Turn off the electrical supply going to the
range.
2. Pull the range away from the wall so that
you can access the rear panel.
3. Remove the eight screws from the rear
panel and remove the panel (see step 4 on
page 3-2).
Indicator Lights
4. To remove an indicator light, push on the
body and slide the clip off the shoulder of
the lens.
5. Disconnect the two indicator wires from
the terminals.
Lens
Push
Indicator Light
Indicator Light
To Next Page
