Item Function Effect
009 DB number Shows identification number of the installation
Fig 4-29 LDU-20 page - HP SCR PAGE INDEX
Tab 4-7 HP SCR PAGE INDEX
Item Function Effect
001 INDEX button Opens the index page
002 SCREENSHOT button Makes a screenshot of the current screen
003 RCS CTRL ON button Gets control from the remote control system (if button is ac-
tive)
004 Page button Opens the selected page
X35-B
AA00-9270-00AAA-043A-A
Operation Manual HP Selective catalytic reduction system
Winterthur Gas & Diesel Ltd.
- 112 - Issue 001 2019-10
