WinGD X35-B - Scavenge Air Receiver - Cross Section (Example)

Fig 5-34 Scavenge air receiver - cross section (example)
001
002
005
004
003
Legend
001 Air space 004 Outlet to piston underside
002 Longitudinal wall 005 Flap
003 Receiver space
X35-B
AA00-6420-00AAA-043A-A
Operation Manual Scavenge air receiver
Winterthur Gas & Diesel Ltd.
- 195 - Issue 001 2019-10
