WinGD X35-B - Ethernet

Electric Connection Diagram
System Layout
W-X35-B
W-X40-B
FEDCBA
Winterthur Gas & Diesel Ltd. retains all rights to this drawing. By taking possession of the drawing, the recipient recognizes and honors these rights. Neither the
whole nor any part of this drawing may be used in any way for construction, fabrication or marketing or any other purpose nor copied in any way nor made
accessible to third parties without the previous written consent of Winterthur Gas & Diesel Ltd. In case of violation, the recipient will be liable to damages.
Mod.
0
1 2 3 4 5 6 7 8 9
1 / 3
CCM-20 A1
Cylinder #1
CCM-20 A2
Cylinder #2
CCM-20 A3
Cylinder #3
CCM-20 A4
Cylinder #4
CCM-20 A5
Cylinder #5
CCM-20 A6
Cylinder #6
IOM-10
LDU-20
LDU-20
(ECR)
CAN
To PCS
Ctrl. Air Press Inl.PT4421C
Common Start Vlv #1CV7013C
Common Start Vlv #2
CV7014C
Aux Blow #1 Start
CY7031C
WasteGateCtrl. Vlv#2
CY7032C
Turn. Gear diseng #1ZS5016C
Turn. Gear diseng #2PT5017C
Aux Blow #1 runningJS5031C
Aux Blow #2 runningJS5032C
Scav Air Press #1 in Air Rec. #1
Starting Air Press #1 Before Shutoff Vlv
Fuel Press #1
PT4043C
PT4301C
PT3461C
Servo Oil Press #1
Main Start Vlv Man. ClosedZS5018C
PT2071C
Scav Air Press #2 Starting Air Press #2
Fuel Press #2 Fuel Press. Supply UnitPT3421C
PT4044C PT4302C
PT3462C
Servo Oil Press #2PT2072C Air Spring Air PressPT4341C
Cyl Cool. Water PressPT1101C
Brng. Oil PressPT2002C
Fuel Press. Ctrl. Vlv Pump. #1
Supply Gear Wheel Sens. B+TDC CV7231C
Fuel Press. Ctrl. Vlv Pump #2
Supply Gear Wheel Sens. C+BDC CV7232C
Serv Oil Pump #1 PCV
Supply Gear Wheel Sens. D CV7221C
Serv Oil Pump #2 PCVCV7222C
UNITool
Ethernet
CAN
CAN
MCM-11
CCM-20 A7
Cylinder #7
TC Speed #1ST5201C
Supply Gear Wheel Sens. A
System Bus 1 + 2
System Bus 1 + 2
System Bus 1 + 2
Gear Sens. A+B
ST5131/32C
Gear Sens. C+D
ST5133/34C
TDC Sign.ZS5123C
BDC Sign.ZS5124C
Gear Wheel Sens. A+BST5131/32C
E25ECR
TCAirTempbef.InletATE4041C TCAirTempbef.InletBTE4042C
TE4045C TCAirTempaft.Cooler A TE4046C TCAirTempaft.Cooler B PT4002C Barometric Press. A PT4003C Barometric Press. B
Waste Gate Ctrl. Vlv
CV7077C
To AMS
CV7076C
Aux Blow #2 Start WasteGateCtrl.Vlv#1
CV7078C
Waste Gate #1 closedZS5372C
Waste Gate #2 closedZS5373C
Waste Gate Pos.XI7077C
HFO SupplyXS3411C
X-Head Brng. Oil Press. SupplyPT2021C
Rail Unit
Ethernet
Modbus
Modbus
FuelPump #1 FCV currentXI3471C
FuelPump #2 FCV currentXI3472C
Servo Oil Pump #1 PCV current
XI2095C
Servo Oil Pump #2 PCV currentXI2096C
