WinGD X35-B - Fuel Leakage Flow from Fuel Rail Items Is too High (Engine with ICU); Fuel Pressure in the Fuel Rail Is too High (for X35 or X40 Engine); Fuel Pressure in the Fuel Rail Is too Low (for X35 or X40 Engine)

Tab 10-31 Fuel leakage flow from fuel rail items is too high (engine with ICU)
Indication Possible cause Procedure
LS3446-47A An injection control unit (ICU) or a
pipe or a connecting pipe (if appli-
cable) is defective
•
Find the cause and repair the defective
item, refer to section [section not applica-
ble for this engine].
Tab 10-32 Fuel pressure in the fuel rail is too high (for X35 or X40 engine)
Indication Possible cause Procedure
PT3461-62C Control signal is missing or wrong
•
Find out the applicable flow control valve.
•
Related to the necessary engine power
close the 3/2-way valve 10-8752_E0_3-4
in the HP fuel pipe of the related fuel
pump.
Flow control valve of a fuel pump
is defective
•
Clean or replace the defective flow control
valve.
Tab 10-33 Fuel pressure in the fuel rail is too low (for X35 or X40 engine)
Indication Possible cause Procedure
PT3461-62C Control signal is missing or wrong
•
Find out the applicable flow control valve.
•
Disconnect the cable of the applicable flow
control valve (The related fuel pump sup-
plies the maximum fuel quantity. The pres-
sure control valve of the fuel rail or the oth-
er fuel pump then controls the fuel pres-
sure).
Flow control valve of a fuel pump
is defective
•
Clean or replace the defective flow control
valve.
