3.6.3 Sash side non-Winkhaus access control system (e.g. Fingerprint
IDENCOM BioKey INSIDE or ekey home SE micro)
Prerequisites for installation
• The applied access control system have to be installed into the door sash.
• If parallel to the sash side access control system another open signal (potential-
free signal: e.g. “Open” button, intercom, ...) should be used for unlocking, this is
possible via the frame part STV-KÜ-T1 RT KABEL 4 M 2 or frame part STV-KÜ-T1
RT KABEL 0,6M RNT + frame power supply STV-NETZTEIL RAHM. 12 V DC 1,5 A
(2 A/2 S) 6 . (see detail A è wires green/white)
• The plugs are protected against polarity reversal and (by right assembly) against
independently solve.
Installation sequence
1. Plug-in the cable of the sash part KÜ-T1-ZK-FL FLÜGELTEIL-EAV
1
with Y-KABEL
ZK FLÜGEL-EAV
3
.
2. Establish a connection between the motor housing EAV
4
and access control
system
5
with the Y-KABEL ZK FLÜGEL-EAV
3
.
CAUTION!
With the combination blueMatic EAV + access control, the power requirement must
not to be fraught more than 2 A!
With the combination with frame power supply STV-NETZTEIL RAHM. 12 V DC
the power supply should be charged max. permanently with 1,5 A and max.
2 A will be charged for 2 s!
NOTICE!
The respective ngerprint or other access control systems are not included in the
Winkhaus scope of delivery.
Fingerprint IDENCOM BioKey INSIDE included in standard delivery IDENCOM. For
further information please contact company IDENCOM (www.idencom.com).
