1.6 Abbreviations/Explanations
The following terms and abbreviations are used in this manual:
STV Security door lock
AV2 autoLock AV2 (Automatic locking system) 2. generation
AV3 autoLock AV3 (Automatic locking system) 3. generation
EAV blueMatic EAV (Automatic locking system with motor operated
opening)
Handle Door handle
Grt. Set
SB FRA Center keeps – latch/deadbolt/adjustment plate
M2 with 2 hooks
RS DIN-right-handed
LS DIN-left-handed
MC Surface matt chrome-plated
EST stainless steel
GR grey powder coated
Reader Reader unit/control unit of the transponder set
AC Alternating current
DC Direct current
NO Make contact
NC Break contact
NO-NC Changer contact
ANT/GND Auxiliary antenna/Ground
UP-socket Flush-type box
LED Light emitting diode
PE Ground wire
N Neutral wire
L Phase
