Installation, Operating and Maintenance
Instructions blueMatic EAV
46
Aug. Winkhaus GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen www.winkhaus.de
Subject to technical changes
3.6.4 Non-Winkhaus access control system ngerprint
Sommer ENTRAsys FD
Prerequisites for installation
• The applied ngprint ENTRAsys FD has to be installed into the door sash.
• If parallel to the ngerprint another open signal (potential-free signal: e.g. “Open”
button, intercom, ...) should be used for unlocking, this is possible via the frame
part STV-KÜ-T1 RT KABEL 4 M 2 or frame part STV-KÜ-T1 RT KABEL 0,6M RNT +
frame power supply
STV-NETZTEIL RAHM. 12 V DC 1,5 A (2 A/2 S)
8 possible. (see
detail B è wires green / yellow)
• The plugs are protected against polarity reversal and (by right assembly) against
independently solve.
Installation sequence
1. Plug-in the cable of the sash part cable transition KÜ-T1-SOMMER-EAV FLÜGEL-
TEIL 1 with 5-pole plug at the
receiver
ENTRAsys FD 6 .
2. Assembly connection between
receiver
ENTRAsys FD 6 and ngerprint ENTRAsys
FD 5 via connection cable Sommer 7 with both sided 2-pole plugs.
3. Assembly connection between receiver ENTRAsys FD 6 and motor housing EAV
4 . For this connect the wires of the included 3 m cable Sommer 3 and put the
3-pole plug into the receiver ENTRAsys FD (see detail A). After that put the blue
plug into the motor housing EAV 4 .
CAUTION!
With the combination blueMatic EAV + access control, the power requirement must
not to be fraught more than 2 A!
With the combination with frame power supply STV-NETZTEIL RAHM. 12 V DC the
power supply should be charged max. permanently with 1,5 A and max. 2 A will be
charged for 2 s!
NOTICE!
Receiver ENTRAsys FD, fingerprint ENTRAsys FD, connection cable Sommer in stan-
dard shipment by Sommer.
