Installation, Operating and Maintenance
Instructions blueMatic EAV
33
3.4 Access control system transponderset
Prerequisites for installation
• The transponder signal is processed in the reader/control unit.
• This unit has to be installed in a standard ush-type box inside the building (close
to the door).
NOTICE!
Should you want to accommodate the control unit and button in the same ush-type
box, this must have a depth of 65 mm.
• Unless you use a button beside the door, you will have to install a ush-type box
with a ller panel for the reader unit.
DANGER!
For safety reasons, do not install it in a ush-type box with a 230 V switch or socket
outlet!
• The transponder antenna is located in a housing for exposed installations and is to
be installed in a weatherproof zone outside the entrance door.
• Do not install the antenna directly on metal as its range could be decreased drasti-
cally.
• Do not install any other antenna within a radius of 1 m!
NOTICE!
If you plan installations on a metal substructure, you will have to use a wooden board
and spacer bolts, if applicable, or large bore holes to ensure the proper function of
the antenna! To test the scanning performance, you may have to tentatively install it
on site, if applicable!
• Connect the cable of the antenna to the reader/control unit.
• We recommend: Lay a reserve pipe from the antenna to the reader unit.
