• the door is drilled through in the area of the lock housings or of the lock rod once
the lock has been installed;
• the additional opening and closing equipment or the thrown deadbolt are impro-
perly used in order to keep the door open;
• force is used to drive the handle pin through the lock spindle;
• the locking components are wrongly installed or are tampered with, e.g. by painting
over movable parts such as the lock deadbolt or latch;
• the locking system is subject to loads which exceed normal manual force and are
transmitted via the cylinder key;
• perform a manual or mechanical locking or unlocking during the motor is working;
• the handle is not loaded in the normal sense of rotation or a a force above 150 N is
applied onto the handle in the direction of actuation;
• the gap between the door frame and sash is increased or decreased, which would
for instance result from readjusting the hinges or if the door drops;
• auxiliary lifting tools or objects are used to open or close the lock;
• the handle and the key are actuated simultaneously;
• the lock is locked/unlocked by using improper tools or equipment;
• Incorrect input values are applied in contravention of the Technical specications.
1.4 Explanation of symbols
Symbols and ags are used to identify important information in this operating manual.
Flags such as DANGER or CAUTION indicate the degree of hazard.
It is imperative that you follow the measures listed to avoid hazard to safety!
DANGER!
Danger to life or danger of serious injuries.
CAUTION!
Danger of material damage.
NOTICE!
Useful information and tips.
