Installation, Operating and Maintenance
Instructions blueMatic EAV
42
Aug. Winkhaus GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen www.winkhaus.de
Subject to technical changes
No. Description No. Description
1
Sash part seperable cable transition STV-KÜ-
T1 SET FT INTEGR-EAV FT 1M + KAB 3M
5
Fingerprint ekey home integra
2
Frame part STV-KÜ-T1 RT KABEL 0,6M RNT
6
Control unit ekey home integra
3
Cable integra-EAV (length 3 m)
7
Cable type „A“ ekey home integra
(length 2 m or 4 m)
4
Motor housing EAV
8
Frame power supply
STV-NETZTEIL RAHM. 12 V DC 1,5 A
3.6.2.1 Control of additional applications (only integra 2)
• The control of a additional application (e.g. garage door, alarm system) takes place
via the second relay of the integra 2.
• This potential-free signal can be used on the green/yellow wires on the frame part
STV-KÜ-T1 RT KABEL 4 M 2 or the signal cable from the frame power supply STV-
NETZTEIL RAHM. 12 V DC 1,5 A 8 (see Detail B è wires green/yellow).
3.6.2.2 Control of swing door opener (integra 1 and 2)
• By using of an blueMatic EAV with a swing door opener a second cable transition
(e.g. STV-KABELÜBERGANG KÜ-T1-STV-FL 3,5M, Art.-No. 4990599 + STV-KÜ-T1
RT KABEL 4M, Art.-No. 5040503) have to be used.
• Instead of the cable integra-EAV 3 m 3
the 3,5 m cable of the additional cable
transition (sash part) will be used.
• With this cable a connection is necessary between the motor housing EAV (blue
plug) and the control unit ekey home integra (length min. 2 m). To this possibly
disconnect the cable and remove the sheathing.
• Put the wire end sleeve at the wires white, brown and green and connect it on ter-
minal X6 according Detail A.
• Two remaining wires (yellow/grey) of the cable from the motor housing have to
be connected with the same colour at the wires (yellow/grey) of the second cable
transition = signal for swing door opener.
• If the cable was separated, connect it with wire connectors.
